● USB 3.1 SuperSpeed, Hi-Speed, Full-Speed, Low-Speed
- Super (5Gbps) / Hi (480Mbps) Full (12Mbps) / Low (1.5Mbps)
● USB 2.0 Compatible
● USB 1.1 Compatible
● USB 3.0 was renamed to “USB 3.1 Gen 1” and operates at up to 5Gbps
● USB 3.1 Gen 2 supports 10GGbps
● Operating Temperature Range: -40°C to +85°C
● Storage Temperature -40° to +85°C
● Humidity 5% to 95% , non-condensing
● Board Dimension: 3.550 x 3.775 inches
● Box Dimension: 3.985 x 3.990 x 1.045 inches
● Weight:
- 284 grams (in enclosure)
- 65.8 grams (-OEM board only version)
● Type A Latching: Retention up to 50 Newtons, Physical shock: Per EIA-364-27 Condition H (11ms 30G), Vibration: Per EIA-364-28D Condition V, Test A
● Type B and A: 8 Newtons disconnect non-locking
● DC Power Jack (locking)
- Vibration: Mil-Std 202G Method 201A
- Insulation Resistance: MIL-STD 202G Method 302 Condition B
- Thermal Shock: MIL-STD 202G Method 107G
- Operating Temperature Rating: -40 °C to +105 °C(-40oF to +221°F)
● DC Power Jack (non-locking): 2.22 Newtons disconnect
● No external power required
● Optional external power: Connect via screw terminals, a locking DC jack / plug or standard jack / plug
● USB 3.1: Up to 480mA at 5VDC required
- Bus Powered: Approximately 420mA available from host for downstream ports; typical consumption at idle: 40mA
- Externally Powered: 900mA available for each downstream port
● USB 2.0: Up to 200mA at 5VDC required
- Bus Powered: Approximately 300mA available from host for downstream ports; typical consumption at idle: 40mA
- Externally Powered: 900mA available for each downstream port
● WI option: Wide Input power from 7VDC to 28VDC at the DC power jack or screw terminals
● The USB 3.1 Gen 1 bus is specified to provide 900mA through the USB cable to most desktop environments.
● This gives you 420mA available on 5VDC (900mA – 480mA = 420mA) for any particular application.
● If using more than a total of 900mA, or your USB port has less then the 900mA normally provided, remove VUSB jumper and place jumper on VEXT.
● This product is designed to be in full compliance with CE requirements.
