● Type F1 “Full Length” V1.2, PCI Express Mini Card (USB signaling)
● Protocols: CAN2.0A, CAN2.0B, CAN2.0FD, 2×Ports provided
● Tru-Iso
- IPC-221B
- Port-to-PC: 1500V peak (AC or DC)
- Port-to-port: 500V peak (AC or DC)
Careful attention has been paid to isolation design, including extensive keep-out zones and hand-routed circuit paths, as well as component and material selection.
● Operating Temperature 0° to +70°C, optional -40° to +85°C
● Storage Temperature -40° to +105°C
● Humidity 5% to 95% RH, without condensation
● Power required:+3.3VDC @ 0.25W (mPCIe-UCAN2-ISO: +3.3VDC @ 0.5W)
mPCIe card characteristics
● Weight:5.4 grams (mPCIe-UCAN2-ISO: 6.2 grams)
● Size: Length: 50.95mm (2.006″); Width: 30.00mm (1.181″)
● I/O connector:
- On-card: Molex 2023960307 3-pin Pico-Clasp
- Mating (On-cable): Molex 5013300300
● This product is designed to be in full compliance with CE requirements.
