● Number of Outputs: 16 channels
● Type of Outputs: Single-ended
● Resolution: 16-bit resolution (12-bit available)
● Unipolar Ranges: 0-10V standard, 0-5V*
● Bipolar Ranges: ±5V standard, ±10V*
● Conversion Rate: 4kHz, all channels simultaneous
● Relative Accuracy: ±4 LSB typical
● Diff. Non-linearity: ±0.25 LSB typical
● Settling Time: 8us typical, 10us max
● Output Current: ±12 mA per channel
● Crosstalk -53dB @ 1MHz;84dB @ 500KHz
● -*Factory Configured
● 3.3V configuration
● Logic High: 2VDC min, 5.5VDC max
● Logic Low: 0.8VDC max, -0.5VDC min
● 5V configuration
● Logic High: 3.5VDC min, 5.5VDC max
● Logic Low: 1.5VDC max, -0.5VDC min
● 3.3V configuration
● Logic High: 2.4VDC min, source 10 mA
● Logic Low: 0.55VDC max, sink 24 mA
● 5V configuration
● Logic High: 3.8VDC min, source 10 mA
● Logic Low: 0.55VDC max, sink 24 mA
● Number of channels: 2
● ADC Type: Successive Approximation
● Sampling Rate: 4k samples per second
● Resolution: 16-bit
● Unipolar range: 0-5V
● Operating Temp.: 0° to 70°C
● Storage Temp.: -40° to +85°C
● Humidity: 5% to 95% non-condensing
● Board Dimension: 3.550 x 3.775 inches
● +12VDC: @ 100 mA typical, no-load on DIO buffer sourced outputs and DAC outputs @ 520 mA typical, full-load on DIO buffer sourced outputs and DAC outputs
● Includes external AC to 12V @ 1Amp DC regulated adapter (not included with -OEM option)
● Optional screw terminal power input
