● High-speed USB 2.0 device, USB 3.0 compatible
● Two 1MHz 16-bit A/D converters for 2MHz aggregate sampling rate
● Analog and digital inputs acquired simultaneously, with timestamping
● 16 kSample FIFO (shared by all inputs)
● Per channel software selectable ranges of 0-1V, 0-2V, 0-5V, 0-10V, ±1V, ±2V, ±5V, ±10V
● Eight digital I/O’s (four inputs & four high-current outputs)
● High retention USB type B connector for vibration-proof, worry-free communications
● Alternate USB micro-fit header can be used to reduce board footprint in embedded applications
● Small rugged steel industrial enclosure
● FACTORY OPTIONS：
- OEM version (board only) features PC/104 module size and mounting compatibility
- Extended temperature (-40° to +85°C)
- External power
- Screw terminals for power input provide high retention connection
- LVTTL DIO lines
- RoHS compliant product
- Support for Wind River VxWorks (call for ordering information)
● Equipment monitoring
● Environmental measurements
● Embedded OEM
● Education/Laboratory
● Portable
● Industrial Automation
● Precision Measurement
● Analysis, Monitoring, and Control
We provide a variety of cables, terminal boards and mounting provisions such as the MP104-DIN for convenient DIN-Rail mounting.
