● 48 or 24 channel high-current TTL digital I/O lines
● Change of State (COS) detection and interrupt capabilities
● Compatible with industry standard 8255 PPI
● 68-pin SCSI pin-in-socket female connector on card mounting bracket
● User interrupt pin
● All 48 digital I/O lines buffered with 32mA source / 64mA sink
● Four and eight bit ports independently selectable for inputs or outputs
● Jumper configurable pull-ups/-downs on DIO lines
● 5V or 3.3V VCCIO configurable by jumper selection
● Poly-fused VCCIO available to the user on each I/O header
● Easy upgrade from PCI-DIO-48JPLS Family devices
● FACTORY OPTIONS:
- Non-latching connector
- Card without Change-of-State IRQ feature
- RoHS compliant version
- Extended temperature operation (-40°C to +85°C)
- Support for Wind River VxWorks (call for ordering information)
● Process Monitoring
● Manufacturing/Production Test
● Machine Control
● Monitoring and Control
● Security Systems, Energy Management
● Industrial Automation
● Factory Automation
● Laboratory Automation
● Embedded OEM
Available accessories include ribbon cables and shielded round-wire molded cable assemblies. Screw terminal boards and DIN-rail mounts are also available for a variety of quick and easy connectivity options.
The card is supported for use in most operating systems and includes a free Linux and Windows compatible software package. This package contains sample programs and source code in Visual Basic, Delphi, and Visual C++ for Windows. Also provided is a graphical setup program in Windows. Linux support includes installation files and basic samples for programming from user level via an open source kernel driver. Third party support includes a Windows standard DLL interface usable from the most popular application programs. Embedded OS support includes the family of Windows Operating Systems including IoT. ACCES is also now offering a VxWorks driver/library for the ultimate real-time process monitoring and control solution.
