● PCI Express
● 5 Volt:
- Input Low ≤ 1.5V, ≤2μA
- Input High ≥3.5V, ≤2μA
- Output Low ≤ 0.55V @ 32mA
- Output High ≥3.8V @ 32mA
● 3.3 Volt:
- Input Low ≤ 0.8V, ≤2μA
- Input High ≥2.0V, ≤2μA
- Output Low ≤ 0.55V @ 24mA
- Output High ≥2.4V @ 24mA
● 2.5 Volt:
- Input Low ≤ 0.7V, ≤2μA
- Input High ≥1.7V, ≤2μA
- Output Low ≤ 0.5V @ 8mA
- Output High ≥1.9V @ 8mA
● 1.8 Volt:
- Input Low ≤ 0.63V, ≤2μA
- Input High ≥1.17V, ≤2μA
- Output Low ≤ 0.45V @ 4mA
- Output High ≥1.2V @ 4mA
● Number / Type Three 82C54 programmable counters
● Counter size 16-bit
● Logic level VCCIO
● On-board clock 1MHz
● Clock Pulse Width High – 30ns (min) Low – 40ns (min)
● Operating Temperature 0° to +70°C
● Storage Temperature -40° to +105°C
● Humidity 5% to 95% RH, without condensation
● Card Dimensions Length – 6.6″; Height – 4.2″ seated
● This product is designed to be in full compliance with CE requirements.
