● Universal PCI, PCI-X, 3.3V and 5V compatible
● 48 bits of digital I/O
● All I/O lines buffered on the card
● I/O buffers can be enabled/disabled under program control
● Four- and eight-bit ports independently selectable for I/O
● Pull-ups on I/O lines
● +5V supply available to the user
● No base address or IRQ switches to set
● RoHS Available. Please contact us for ordering information
● Support for Wind River VxWorks (call for ordering information)
● Automatic Test Systems.
● Security Systems, Energy Management.
● Robotics.
● Relay Monitoring and Control.
● Parallel Data Transfer to PC.
● Sensing switch closures or TTL, DTL, CMOS Logic.
● Driving Indicator Lights or Recorders.
Drivers for various operating systems are also provided, including active support for Windows XP -> 10 — all in both 32-bit and 64-bit flavors, and including consumer, server, and embedded varieties — as well as the 2.6 and newer Linux kernels and recent OSX / macOS versions. Many products continue to ship with driver support for Windows 95, 98, Me, NT4, and Windows 2000, but support for these operating systems is considered deprecated.
