● PCI Bus
● I/O Connections: Via a 68-pin, shielded, VHDCI connector. There are 9 pins per port including common grounds. All RS-232 signals are supported and present at the DB-9 connectors
● Cable: Breakout Cable from VHDCI Connector is secured to card using jack screws, with a DB9 connectors provided for each port.
● Character Length: 5,6,7, or 8 bits.
● Parity: Even, odd, or none.
● Stop Interval: 1, 1.5, or 2 bits.
● Serial Data Rates: Up to 115,200 baud, asynchronous. A faster range of rates, up to 921k baud, is achieved by jumper selection on the card prior to installation.
● Multidrop: Compatible with RS-485 specifications. Up to 32 drivers and receivers allowed on line. Driver/Receivers used are type SP491.
● Rec.Input Sensitivity: ±200 mV differential input.
● Common Mode Voltage Range: +12V to -7V.
● Transmitter Output Drive Capability: 60 mA with thermal shutdown.
● Operating Temperature Range: 0 to +60°C.
● Storage: -25 to +85°C
● Humidity: 0 to 90 percent (non-condensing)
● Power Required: +5 VDC at 200 mA typical, 1300 mW total power consumption.
● Size: 6.6″ long (167.64mm) by 2.21″ tall (56.17mm) seated height.
● This product is designed to be in full compliance with CE requirements.
