● ISA Bus
● Number of inputs: 8
● Type: Non-polarized, optically isolated from each other and from the computer. (not TTL/CMOS compatible)
● Voltage Range: 5 to 24V DC or AC (50 to 1000 Hz)
● Isolation: 60V channel-to-ground or channel-to-channel
● Input Resistance: 470 ohms in series with two diodes and an LED
● Response Time: 20 mSec w/filter, 10 uSec w/o filter
● Number of outputs: 8
● Contact Rating: 2A carry current, bifurcated, gold clad, silver palladium
● Contact Arrangement: Channels 0-4 are SPDT Form C and channels 5-7 are SPST Form A
● Contact Rating: Initial 100 milliohms maximum
● Contact Life: mech’l: 5 million operations minimum; elect’l: 500,000 operations minimum at full load
● Operating Time: 2 milliseconds maximum
● Release Time: 1 milliseconds maximum
● When enabled by software and by installation of level-select jumpers, interrupts are generated when digital inputs change state.
● Operating Temperature Range: 0° to 60°C.
● Storage Temperature Range: -40° to +100°C.
● Humidity: 0 to 90% RH, non-condensing.
● +5VDC @ 1 A (all relays ON)
● This product is designed to be in full compliance with CE requirements.
