Ethernet網絡模塊系列產品
ETH-IDIO-16 產品技術規格
Isolated Inputs

● Channels: 4, 8, or 16

● Type: Non-polarized, optically isolated from each other and from the computer (CMOS-compatible)

● Voltage: 3 to 31VDC or AC RMS (40 to 1000Hz)

● Isolation: 500V channel-to-ground and channel-to-channel (see manual)

● Response Times:

- Filtered: 4.7ms rise and fall

- Non-Filtered: 10μs rise; 30μs fall

Solid State Relay (FET) Outputs

● Channels: 4, 8, or 16

● Type: High-Side Power MOSFET Switch. Protected against short-circuit, over-temperature, ESD, and can drive inductive loads.

● Voltage Range: 5-34VDC recommended for continuous use. 40VDC absolute max. (customer supplied)

● Current Rating: 2A max

● Turn-on time: 90μS typical

● Turn-off time: 110μS typical

Bus Type

●thernet 10/100 Base T, Auto-detecting, 1.5kV Isolation

Environmental

● Operating Temperature Range: 0°C to 70°C (Optional -40°C to +80°C)

● Storage Temperature Range: -40°C to +85°C

● Humidity: 5%-90%, non-condensing

Mechanical

● Board Dimension: 3.550 x 3.775 inches

● Box Dimension: 4.00 x 4.00 x 1.7 inches

● Connectors:

- Isolated Inputs: Dual row 0.1” 34-pin

- Relay Outputs: Dual row 0.1″ 50-pin

- DC power jack: 2.0mm + center post

- Screw terminals: Available via enclosure cutout

Power

● External AC/DC 5V regulated power is required

● 5V @ 35mA plus 5mA per energized FET; 5V @ 115mA with all FETs on, typical
