● RJ45 Ethernet：10/100/1000 Base-T
● ADC Type: Successive approximation
● Resolution:16-bit
● Sampling Rate: 1 Msps aggregate
● Number of Channels: 16 Single-Ended or 8 Differential inputs software control)
● Ranges: 0-1V, 0-2V, 0-5V, 0-10V, ±1V, ±2V, ±5V, ±10V (software selectable)
● Int Nonlinearity Error: 0.0011% FS
● No Missing Codes: 16 bits
● Input Impedance: 1MΩ
● A/D Start Sources: Software Start, Timer Start, External Start, Externally Triggered Timer Start
● A/D Start Types: Single Channel or Scan
● Overvoltage Protection: -40 to +40V
● Crosstalk:
-53dB @ 1MHz
-84dB @ 500kHz
● Number: 4
● Type: Single-Ended
● Resolution 16-bit
● Unipolar Ranges: 0-5V, 0-10V (factory configured)
● Bipolar Ranges: ±5V, ±10V (factory configured)
● Settling Time: 20us typical, +/-10V (+/-1LSB at 16 bits)
● Output Current: max ±10mA per channel
● Digital Bits: 16, individually direction controllable
● Digital Inputs:
- Logic low: -0.5V to 0.3V x V_DIO
- Logic high: 0.7V x V_DIO to 5.5V
● Digital Outputs:
- Logic low: 0.5V (max) 24mA sink
- Logic high: 2.0V (min) 24mA source
● On card:
68pin SCSI female .050 Series, Amplimite, PN 1761028-4
● Power required, PoE
● Power required, External:12VDC to 30VDC @ TBD
● Operating Temperature 0° to +70°C, optional -40° to +85°C
● Storage Temperature -40° to +105°C
● Humidity 5% to 95% RH, without condensation
● Dimensions: PC/104 format,3.550” by 3.775” w/mounting holes
● This product is designed to be in full compliance with CE requirements.
