PC/104 架構帶隔離Digital Inputs/Outputs模塊系列產品
104-IIRO-8 產品技術規(guī)格
PC Interface

● PC/104

Isolated Digital Inputs

● Number of Inputs: Eight

● Type: Non-polarized, optically-isolated from each other and from the computer. (CMOS compatible).

● Voltage Range: 3 to 31V DC or AC RMS (50 to 10 KHz)

● Isolation: 500V

● Input Resistance: 1.8KΩ in series with opto-coupler.

● Response Time: 4.7 milliseconds w/filter, 10usec w/o filter

TTL Digital Inputs

● Number of Inputs: Eight

● Type: TTL, 10K pull up to 5V

● Purpose: For reading dry contact closures or any TTL compatible outputs

Relay Outputs

● Number of Outputs: Eight

● Type: SPDT Form C Relay – Omron G5V-1

● Contact Ratings: 1A @ 24VDC (60VDC max), 0.5A @ 125VAC carry current

● Contact Type: Single crossbar Ag with Au clad (bifurcated contacts optional)

● Contact Arrangements: Channels 0-7: SPDT Form C

● Contact Resistance: Initial, 100 mΩ maximum

● Contact Life: Mechanical: 5 million operations minimum

● Operating Time: 5 milliseconds maximum

● Release Time: 5 millisecond maximum

● Regulatory Approvals: UL and CSA

Interrupts

● When enabled by software, interrupts are generated when any isolated digital input changes state (High to Low or Low to High, and from signal to no signal with AC inputs).

Environmental

● +5VDC at 0.4A (all relays ON)

● Ambient Temperature: Operating: -30°C to 70°C. (non-icing)

● Weight: Approx. 4 oz. (~115 grams)

Regulatory Compliance

● This product is designed to be in full compliance with CE requirements.
