● PC/104
● Number and Type: 32, non-polarized, optically isolated from each other and ground
● Voltage Range: 3 to 31 volts DC or AC Rms ( 40 to 10000 Hz ), CMOS compatible
● Isolation: 500V*(see manual) channel-to-ground and channel-to channel
● Input Resistance: 1.8K ohms in series with opto coupler (two LEDs)
● Response Time: 4.7 mSec w/filter, 10 μSec w/o filter (typical)
● Number of outputs: Four SPDT form C
● Contact Type: Single crossbar; Ag with Au clad
● Carry Current: 2A
● Rated Load AC: 0.5 A at 125 VAC (62.5 VA max )
● Rated Load DC: 1 A at 24 VDC ( 30 W max )
● Switch Voltage / Current: 125 VAC; 60 VDC / @ 1A (max)
● Contact Resistance: 100 mΩ max
● Max. Switching Voltage: 125 VA, 60 VDC
● Max. Switching Current: 1A
● Max. Carrying Current: 2A
● Contact Life-mechanical: 5,000,000 operations min
● Operating / Release Time: 5 ms max (mean value: approx 2.5 ms, and 0.9 ms respectively)
● Generated when inputs change state if enabled by software and jumper selected IRQ
● IRQ Sharing via tri-stated line driver on jumper selected interrupt line (positive edge true)
● +5 VDC @ 150 mA (all inputs HI & all relays ON, no load on fused 5V power)
● +5 VDC power is provided via a resettable polyfuse (at 0.5A) for application and general purpose usage
● Operating temperature: 0°C to +70°C, optionally -40°C to +85°C available
● Storage temperature: -50° to +120°C
● This product is designed to be in full compliance with CE requirements.
