● PC/104
● Two shielded male D-sub 9-pin connectors compatible with RS-485 and RS-422 specifications.
● Character Length: 5, 6, 7, or 8 bits.
● Parity: Odd, even, or none.
● Stop Interval: 1, 1.5, or 2 bits.
● Serial Data Rates: Up to 115,200 baud asynchronous, 460,000 Baud optional.
● Asynchronous Communication Element: Type 16C550 UART which includes 16 byte FIFO.
● Receiver Input Sensitivity: ±200 mV differential input.
● Common Mode Voltage Rejection: +12V to -7V.
● Transmitter Output Drive Capability: 60 mA.
● Operating Temperature Range: 0° to +60°C, (-40° to +85°C Optional)
● Storage Temperature Range: -50 to +120°C
● Humidity: 5% to 95% RH, non-condensing
● Power Required: +5VDC at 200mA typical, all outputs open
● CE testing & approval must be done at the system level, in the designed enclosure, and is not done on individual boards.
